10 T Large Capacity Electric Wire Rope Hoist with 220v-440v,50HZ/60HZ Power and 6m Lifting Height

Brand Name : JCYC

Model Number : HC-A & HC-B

Certification : CE&ISO

Place of Origin : China

MOQ : 1 unit

Price : $500-$10000

Payment Terms : L/C,T/T,Western Union

Supply Ability : 500 pcs per month

Delivery Time : 10 -15 working days

Packaging Details : Plywood case

Product name : 10 T Large Capacity Electric Wire Rope Hoist Blue Color

Capcity : 0.25t-50t

Standard Lifting height : 6m

Color : Blue

Voltage : 220v-440v,50HZ/60HZ

Usage : Lifting goods

Contact Now

10 T Large Capacity Electric Wire Rope Hoist Blue Color

HC-A & HC-B Model, Electric Wire Rope Hoist

It is a lifting equipment which designed on the basis of CD1/MD1.

Widely used in factories, mines, harbours, warehouses, cargo storage areas and shops, essential in raising working efficiency and improving working conditions.

Product Details:

HC-A HC-B Electric Wire Rope Hoist

Features and advantages:
  • Color variety.
  • Different power supply is available.
  • High quality material includes Q235B Schneider Control box, 20 Chromium manganese titanium gear and 40 chromium forge hook, etc.
  • Transmission shaft: 45#quenched and tempered steel; with thicken steel plate cover and coiling block.
  • High quality and wide adaptation.
  • Excellent performance.
  • 1 year warranty
  • Sample, OEM or ODM is ok.
Model Lifting Capacity(t) Lifting Height(m) Lifting Speed(m/min) Running Speed(m/min) Wire Rope Type Dia. Of Wire Rope I Beam Track Type Working Duty Lifting Motor Running Motor
Power(kw) R.P.M(r/min) Power Supply Power(kw) R.P.M(r/min) Power Supply
HC-A0.25 0.25 3-9 8 20 6*19 3.6 16-22b M3 0.4 1380 220-440V 50/60HZ, 3 Phase 0.06 1400 220-440V 50/60HZ, 3 Phase
HC-A0.5 0.5 6-12 8 20 6*37+1 4.8 16-28b M3 0.8 1380 0.2 1380
HC-A1 1 6-30 8 20 6*37+1 7.4 16-28b M3 1.5 1380 0.2 1380
HC-A2 2 6-30 8 20 6*37+1 11 20a-32c M3 3 1380 0.4 1380
HC-A3 3 6-30 8 20 6*37+1 13 20a-32c M3 4.5 1380 0.4 1380
HC-A5 5 6-30 8 20 6*37+1 15 25a-63c M3 7.5 1380 0.8 1380
HC-A10 10 6-30 7 20 6*37+1 15 25a-63c M3 13 1400 0.8*2 1380
HC-A16 16 6-30 3.5 20 6*37+1 15 45a-63c M2 13 1400 0.8*2 1380
HC-A20 20 6-30 3.5 20 6*37+1 20 50a-63c M2 13 1400 0.8*2 1380















Model Lifting Capacity(t) Lifting Height(m) Lifting Speed(m/min) Running Speed(m/min) Wire Rope Type Dia. Of Wire Rope I Beam Track Type Working Duty Lifting Motor Running Motor
Power(kw) R.P.M(r/min) Power Supply Power(kw) R.P.M(r/min) Power Supply
HC-B16 16 9-48 3.5(3.5/0.35) 20 6*19 17.5 50a-63c M3 13(13/1.5) 920(1400) 220-440V 50/60HZ, 3 Phase 0.8*2 1380 220-440V 50/60HZ, 3 Phase
HC-B20 20 9-24 3.5/0.3(4/0.4) 20 6*37+1 20 50a-63c M6 18.5(18.5/3) 920(1400) 0.8*4 1380
HC-B25 25 9-24 2.4/0.24(3/0.3) 20 6*37+1 20 50a-63c M6 18.5(18.5/3) 920(1400) 0.8*4 1380
HC-B32 32 9-24 2.4/0.24(3/0.3) 20 6*37+1 26 50a-63c M3 18.5(18.5/3) 920 1.5*4 1380
HC-B50 50 9-24 2.4/0.24 20 6*37+1 26 50a-63c M3 18.5(18.5/3) 920 1.5*4 1380
HC-B80 80 9-24 2.4/0.24 20 6*37+1 26 50a-63c M3 18.5(18.5/3) 920 1.5*4 1380
